1, Product Name : Centrifugal Slurry Pump Parts A05 R26 Impeller Volute Liner

1. Brife Introduction :
Slurry pump parts

Completely interchangeable with NH, L, M, HH, SP slurry pumps and G/GH gravel pumps

For unlisted slurry pump parts, OEM service offered. Drawings needed.

Materials

High chrome alloy: A05, A07, A49, etc.

Natural rubber: R08, R26, R33, R55, etc.

Other material as per requests, like stainless steel, duplex stainless steel, Nickle alloy, Alloy 20, etc.

Short delivery time

For some parts, stocks are available. We have large producing capacity to shorten the delivery time.

OEM part codes

Here we list some OEM part codes for reference:
Impeller: 127, 147, 145, etc., such as C2127, D3147, E4147, F6147, G8147, G10147, FAM1247...
Volute liner, C2110, D3110, E4110, F6110, G10110, G12110, ...
A H Series Heavy Duty Slurry Pump Throat Bush code:
6/4 D-A H Slurry Pump  code: E4083
6/4 E-A H Slurry Pump  code: E4083
8/6 E-A H Slurry Pump  code: F6083
8/6 F-A H Slurry Pump  code: F6083
10/8 F-A H Slurry Pump  code: F8083
10/8 ST-A H Slurry Pump  code: G8083
12/10 ST-A H Slurry Pump  code: G10083
14/12 ST-A H Slurry Pump  code: G12083

G Series Sand Gravel Pump
12/10G-G Sand Gravel Pump Throat Bush code: FG10013
14/12G-G Sand Gravel Pump Throat Bush code: GG1412013

Frame & Bearing Assembly types

Types: B, C, D, E, F, R, X, ST, T, TU, CC, DD, EE, FF, etc.

2, Models and introductions

3, Pictures

4, Applications

This Series of Pumps are used conveying abrasive or corrosive slurry, especially clinker of power plants in electric power, metallurgy, mining, coal, building materials, chemical industry and other industrial sectors,etc.
